C6012 Alien Higgs 3 RFID Tag

Description

The RFID ceramic tag is a compact, high-performance RFID transponder engineered for reliable use in harsh industrial and mission-critical environments. It is constructed with a high-dielectric ceramic substrate, ensuring strong RF stability and consistently reliable read performance, particularly on metal surfaces where standard RFID labels may underperform.

Designed for long-term durability, this ceramic-based RFID tag maintains stable operation even under extreme conditions, including exposure to moisture, high temperatures, chemicals, and other demanding industrial factors. It is widely used for asset tracking, equipment identification, and industrial management applications that require both robustness and consistent RFID accuracy.

The RFID Ceramic Tag is a compact, high-performance RFIDtransponder designed for reliable operation in harsh industrialenvironments. Built on a high-dielectric ceramic substrate, thetag delivers excellent RF stability, superior performance onmetal surfaces, and long-term durability under extremeconditions,such as wetness,high temperature,chemicals,etc.

They can be attached to objects for various applications, suchas inventory management, supply chain tracking, assettracking, aerospace, chemical, automotive, andmanufacturing, and product authentication.

Specifications

RFID Features	Mdoel	C6012
	Air Interface Protocol	EPC Class 1 Gen 2 / ISO 18000-63 Type C
	Frequency	860-960 MHz
	Chip Type	Alien Higgs 3
	Memory	User - 512 bits; EPC - 96 bits; TID - 96 bits
	Data Storage	> 10 years
	Re-write	100,000 times
	Read Range(2W ERP)	FCC: > 4.0 m(13.1 ft) , on metal ETSI: > 3.0 m(9.8 ft) , on metal
Physical Features	Dimension	4 x 4 x 3 mm / 0.16 x 0.16 x 0.12 in
	Material	Ceramic
	Weight	0.25 g
	Color	Black
	Operating Temperature	-40°C to 85°C / -40°F to 185°F
	Survival Temperature	-40°C to 250°C / -40°F to 482°F
	Storage Condition	20±5℃, 50±10% RH, Store away from sunlight
	IP Rate	IP68, test for 5 hours at 1m deep water
Other Features	Installation	Adhesive(clean and dry surface), Rivet, Magnet, Screw
	Customization	Printing, Encoding, Design, etc.
	Application	Medical device / Equipment & tool

Highlights & Benefits

Superior RF,thermal and mechanical stability

Resistant to heat, moisture, chemicals,ray

Longer lifespaneven in harsh environments

Miniaturization,long read range evensmall size

Sterilizable and biocompatible

Applications

Medical device

Equipment & tool

Technical Features

Model	C6012
RFID Features
Air Interface Protocol	EPC Class 1 Gen 2/ISO 18000-63 Type C
Frequency	860-960 MHz
Chip Type	Alien Higgs 3
Memory	User-512 bits;EPC-96 bits; TID-96 bits
Data Storage	>10 years
Re-write	100,000 times
Read Range(2W ERP)	FCC:>4.0 m(13.1 ft), on metal ETSI:>3.0m(9.8 ft), on metal
Physical Features
Dimension	4x4x3mm/0.16x0.16x0.12 in
Material	Ceramic
Weight	0.25g
Color	Black
Operating Temperature	-40℃ to 85C /-40°℉ to 185℉
Survival Temperature	-40℃ to 250℃/-40°℉ to 482°℉
Storage Condition	20± 5℃, 50± 10% RH, Store away from sunlight
IP Rate	IP68,test for 5 hours at 1m deep water
Other Features
Installation	Adhesive(clean and dry surface), Rivet, Magnet, Screw
Customization	Printing, Encoding, Design, etc.
