Hydro LA421-H 70x15mm NXP Ucode 9xe

Description

Constructed with a flexible antenna and woven fabric, this Sunrfid UHF laundry tag is specifically engineered for commercial linen tracking. It survives over 200 industrial wash cycles, offering a slim profile, extended read range, and resilience against high pressure and heat. By assigning a unique global ID to each textile item, users can perform rapid batch scanning via RFID readers to automatically track usage and laundry frequency. This Sunrfid solution makes handover processes transparent and accelerates inventory audits. Furthermore, the collected data allows for accurate lifespan prediction and smarter procurement planning for your linen assets.

Technical Features

Physical Features	Model	Hydro LA421-H
	Material	Polyester
	Length x Width	70 x 15 mm (2.7 x 0.6 in)
	Thickness	1.40mm(0.06 in) on chip location only, Rest of tag is 0.65 mm(0.03 in)
	Weight	0.55 g
RFID Features	RFID Standard	EPC C1G2 (ISO18000-6C)
	Frequency	860-960 MHz(worldwide)
	Chip Type	NXP Ucode 9xe
	Memory	User-N/A; EPC-128 bits; TID-48 bits
	Data Storage	> 20 years
	Re-write	100,000 times
	Read Range(Fixed Reader)	FCC: > 9.0 m (29.5 ft); ETSI: > 12.0 m (39.4 ft)
	Read Range(Handheld Reader)	US: >10.6 m(35 ft); EU: >9.0 m(30 ft)
Other Features	Installation	Hang or pouch
	Warranty	200 washing cycles or 3 years, whichever comes first
	Washing Method	Laundry, Dry cleaning
	Water Extraction pressure	60 bars
	Chemical Resistance	Detergent, Softener, Bleach (Oxygen/ Chlorine), Alkali
	Washing Temperature	90°C (194°F)/15 minutes
	Pre-drying in Tumble	180°C (356°F)/30 minutes
	Ironing Tempereature	185°C (365°F)/10 seconds
	Sterilization Tempereature	135°℃ (275°F)/20 minutes
	Humidity/ Temperature-Operating	-20~+85℃(-4~185℉)/ 8-95%RH
	Personalization	Printing, Encoding, Design, etc.
	Package	1000 pcs / bag, 15 bag / box
	Applications	Industrial washing/Management of uniforms Medical apparel management/Military clothing management
